Model：
|
NO |
Product attributes |
| |
|
1 |
Rated working pressure |
PN |
1.0-1.6Mpa |
|
2 |
Test pressure |
Shell |
1.5-2.4Mpa |
|
Seal |
1.1-1.76Mpa | ||
|
3 |
working temperature |
T |
0-100℃ |
|
4 |
Applicable media |
Freshwater, sea water, air, weak acids and bases, etc. | |
|
NO |
Name |
Texture of material |
NO |
Name |
Texture of material |
|
1 |
Actuator |
Aluminum alloy shell |
8 |
Upper valve shaft |
304、316、416stainless steel, 45 # carbon steel |
|
2 |
Connecting bolt |
45#、Stainless Steel |
9 |
Seat backrest |
phenolic resin |
|
3 |
O-ring |
NBR |
10 |
Valve plate |
QT450 nickel plating, QT450 nylon coating, aluminum bronze, 304, 316, 316L, 2507, 1.4469, 1.4529 |
|
4 |
Anti-backlash clip spring |
50#Manganese Steel |
11 |
Backstop rod |
UPVC、45# |
|
5 |
Backstop ring |
45#Galvanizing |
12 |
Lower Valve Shaft |
304, 316, 416 stainless steel, 45 # carbon steel |
|
6 |
Round gasket |
45#Galvanizing |
13 |
Seat rubber |
EPDM, NBR, FTFE, silica gel, fluorine gel |
|
7 |
Lubricating sleeve |
Teflon |
14 |
valve body |
HT200, QT450, Stainless Steel, Cast Steel |
|
DN |
ΦD |
n-M1 |
H1 |
H2 |
H3 |
L1 |
L2 |
L3 |
L4 |
|
DN40 |
110.00 |
4-M16 |
71 |
212.0 |
92.0 |
33.5 |
30 |
71.5 |
147 |
|
DN50 |
125.00 |
4-M16 |
70 |
237.5 |
107.5 |
42 |
32 |
83 |
168 |
|
DN65 |
145.00 |
4-M16 |
80 |
250.5 |
107.5 |
45 |
47 |
83 |
168 |
|
DN80 |
160.00 |
4-M16 |
94 |
274.5 |
119.5 |
45 |
65 |
95 |
184 |
|
160.00 |
8-M16 | ||||||||
|
DN100 |
180.00 |
8-M16 |
108 |
298.7 |
128.7 |
52.1 |
91 |
103 |
204 |
|
DN125 |
210.00 |
8-M16 |
122 |
326.5 |
136.5 |
55 |
112 |
108.5 |
262 |
|
DN150 |
240.00 |
8-M20 |
134 |
363.0 |
153.0 |
56 |
146 |
121.5 |
268 |
|
DN200 |
295.00 |
8-M20 |
167 |
418.0 |
175.0 |
61 |
194 |
142 |
301 |
|
295.00 |
12-M20 | ||||||||
|
DN250 |
350.00 |
12-M20 |
203 |
474.0 |
192.0 |
66 |
242 |
152 |
390 |
|
355.00 |
12-M24 | ||||||||
|
DN300 |
400.00 |
12-M20 |
241 |
527.0 |
217.0 |
77 |
292 |
174 |
458 |
|
410.00 |
12-M24 | ||||||||
|
DN350 |
460.00 |
16-M20 |
267 |
613.0 |
260.0 |
77 |
325 |
206 |
525 |
|
470.00 |
16-M24 | ||||||||
|
DN400 |
515.00 |
16-M24 |
310 |
665.0 |
285.0 |
87 |
380 |
226 |
532 |
|
525.00 |
16-M27 | ||||||||
|
DN450 |
565.00 |
20-M24 |
331 |
730.0 |
319.0 |
105 |
428 |
260 |
602 |
|
585.00 |
20-M27 | ||||||||
|
DN500 |
620.00 |
20-M24 |
379 |
824.0 |
356.0 |
130 |
474 |
294 |
722 |
|
650.00 |
20-M30 | ||||||||
|
DN600 |
725.00 |
20-M27 |
463 |
942.0 |
380.0 |
152 |
573 |
336 |
760 |
|
770.00 |
20-M33 |
