Model：
|
NO |
Product attributes | ||
|
1 |
Rated working pressure |
PN |
1.0-1.6Mpa |
|
2 |
Test pressure |
Shell |
1.5-2.4Mpa |
|
Seal |
1.1-1.76Mpa | ||
|
3 |
working temperature |
T |
0-100℃ |
|
4 |
Applicable media |
Freshwater, sea water, | |
|
NO |
Name |
Texture of material |
NO |
Name |
Texture of material |
|
1 |
Actuator |
Aluminum alloy shell |
8 |
Upper valve shaft |
416SS |
|
2 |
Connecting bolt |
Stainless steel |
9 |
Seat backrest |
phenolic resin |
|
3 |
O-ring |
NBR |
10 |
Valve plate |
316L |
|
4 |
Anti-backlash clip spring |
50#Manganese Steel |
11 |
Backstop rod |
UPVC、45# |
|
5 |
Backstop ring |
45#Galvanizing |
12 |
Lower Valve Shaft |
416SS |
|
6 |
Round gasket |
45#Galvanizing |
13 |
Seat rubber |
Corrosion Resistant EPDM |
|
7 |
Lubricating sleeve |
Teflon |
14 |
valve body |
304SS |
|
DN |
ΦD1/ΦD2 |
4-Φd1 /∮d2 |
H1 |
H2 |
H3 |
L1 |
L2 |
L3 |
L4 |
|
DN50 |
107.00 |
19.00 |
61 |
236.5 |
107.5 |
42 |
32 |
71.5 |
168 |
|
125.00 |
19.00 | ||||||||
|
DN65 |
119.00 |
19.00 |
82 |
253.5 |
107.5 |
45 |
47 |
83 |
168 |
|
145.00 |
19.00 | ||||||||
|
DN80 |
154.50 |
23.00 |
94 |
277.5 |
119.5 |
45 |
65 |
83 |
184 |
|
155.75 |
24.00 | ||||||||
|
DN100 |
175.00 |
19.00 |
105 |
302.7 |
128.7 |
52.1 |
91 |
95 |
204 |
|
190.50 |
19.00 | ||||||||
|
DN125 |
210.00 |
23.00 |
123 |
329.5 |
136.5 |
55 |
112 |
103 |
262 |
|
216.00 |
23.00 | ||||||||
|
DN150 |
240.25 |
23.50 |
137 |
367.0 |
153.0 |
56 |
146 |
108.5 |
268 |
|
240.25 |
23.50 | ||||||||
|
DN200 |
292.00 |
24.60 |
164 |
418.0 |
175.0 |
61 |
194 |
121.5 |
301 |
|
296.00 |
25.00 | ||||||||
|
DN250 |
357.00 |
30.00 |
195 |
474.0 |
192.0 |
66 |
242 |
142 |
390 |
|
357.00 |
30.00 | ||||||||
|
DN300 |
400.00 |
25.00 |
232 |
527.0 |
217.0 |
77 |
292 |
174 |
458 |
|
432.00 |
26.00 | ||||||||
|
DN350 |
460.00 |
23.00 |
264 |
625.0 |
260.0 |
77 |
325 |
206 |
525 |
|
470.00 |
26.00 | ||||||||
|
DN400 |
515.00 |
26.00 |
325 |
673.0 |
285.0 |
87 |
380 |
226 |
532 |
|
525.00 |
30.00 | ||||||||
|
DN450 |
565.00 |
26.00 |
330 |
736.0 |
319.0 |
105 |
428 |
260 |
602 |
|
585.00 |
30.00 | ||||||||
|
DN500 |
620.00 |
26.00 |
363 |
836.0 |
356.0 |
130 |
474 |
294 |
722 |
|
650.00 |
33.00 | ||||||||
|
DN600 |
725.00 |
20-Φ30 |
459 |
942.0 |
380.0 |
152 |
573 |
336 |
760 |
|
770.00 |
20-Φ36 |
